RFID TUNNEL
Traceability, Localization, Access Control
Indevo UHF Tunnels are structures designed for the identification of pallets/goods in transit
We have been developing custom projects based on RFID technologies for over 10 years.
We offer consulting services, provide the most suitable RFID solutions, and offer post-installation support in Italian.
Our experience allows us to develop customized RFID systems even in situations where radio frequency signals are difficult to use, such as in the presence of metal plates, which tend to shield the signal.
Indevo UHF tunnel is designed to work with any conveyor belt. An entrance door with metal bulkheads located at the beginning of the tunnel allows you to perfectly read the different moving packages even if they are close together.
The wire mesh at the side of the tunnel prevents unwanted tags from being read near the tunnel.
Thanks to the special RFID antennas which have advanced technical characteristics and high performance, it is possible to have an extremely reliable and stable reading on packaged articles by focusing the radio frequency field in order to penetrate deeply inside the boxes.
The dimensions are customizable. Built from lightweight aluminum and stainless steel, it presents itself as a leading solution on the market.
INX022 UHF TUNNEL
|
Operating frequency |
865-868 MHZ (EU), 902-928 MHZ (USA) |
|
External dimensions (L X W x H) |
1500 X 1200 |
|
Maximum internal dimensions (W x H) |
550 X 500 mm |
|
Minimum length of the conveyor belt |
1600 mm |
|
Weight (only Tunnel) |
approx. 100 kg |
|
Distance between packages* |
Recommended 200 mm |
|
Typical speed conveyor* |
Between 15 m/min |
|
Interface |
Ethernet 10/100 BaseT |
|
Data format |
EPC followed by CRLF in text format APIs available with REST call |
|
Power supply (V) |
Reading unit: 24 Vdc 2.0A |
|
Typical power consumption |
approx. 50 w |
|
Operating temperature |
From 0°C to +50°C |
|
Internal display |
Upon request |
RFID systems are eligible for Industry 4.0 incentives
Get the best solution for your business
RFID Technology:
monitoring goods and optimizing production
RFID solutions can be used along the entire production and goods handling chain, meeting a variety of needs:
Traceability
Unique identification of an entity. Track the movements of raw materials and semi-finished products on pallets handled by forklifts or forklift trucks in general.
Inventory
Reduction in inventory execution costs by automatically checking whether a tool or raw material is present in cabinets and shelving.
Warehouse mapping
Speeded up identification process and no longer entrusted to the operator’s memory, therefore free from risk of error.
Product identification
Traceability of uniquely identifiable objects. Recognition and identification of components to be processed.
Fraud prevention
It assigns a unique label to each object, that cannot be read by those who are not authorized.
Access control
Attendance tracking linked to the staff management software.
Shipping
Reading of pallets loaded on trucks through the gate.
The Indevo UHF RFID Tunnel represents the most advanced evolution for the automatic identification of goods flows in the supply chain.
It is a system integrated into a conveyor belt, equipped with strategically positioned UHF readers and antennas, which creates a shielded “reading corridor”. Our tunnel is designed to identify hundreds of items per second in bulk mode (multiple reading), even inside boxes and without the need for a line of sight, transforming logistics and production processes in terms of speed, accuracy and efficiency.
The UHF RFID tunnel is not just an enhanced tag reader, but an enabling infrastructure for Industry 4.0. It turns a manual, slow, error-prone process into an automated, fast, and reliable data workflow.
